PCB Depanelling Machine

Double Spindle Online Milling PCBA Depanelling Router


HR910LAT Dual-Spindle Online Depanelling Router
I. Product features:

1. Online milling cutter board splitter, automatic board feeding, automatic cutting, automatic board output, greatly improves production efficiency and saves labor costs, reflecting a fully automated production line.

2. Dual-spindle, dual-workbench structure design improves cutting efficiency.

3. The dual working platform uses independent spindles to cut and split boards at the same time, greatly improving the cutting capacity and efficiency.

4. The entire system is equipped with a CCD visual alignment system to improve cutting accuracy and efficiency and prevent misoperation.

5. The X-axis and Y-axis use high-precision dustproof modules to ensure that the setting cutting is stable and accurate.

6. The standard Japanese imported laser shifter detects whether the PCBA product is flat.

7. Automatic material picking uses vacuum suction cups for picking and placing.

8. An independent CNC dedicated motion controller is used to integrate the control part, with strong circuit control stability, high accuracy, fast corresponding transmission, and strong anti-interference.

9. The equipment operation adopts Chinese/English interface conversion, the software design is more user-friendly and easy for engineers to operate.

10. It has the function of cutting straight lines, arcs and irregular plate edges, and realizes the functions of broken knife detection and slipping knife detection.

11. It adopts the imported high-speed spindle Max: 80,000RPM from German Sycotec, with small cutting stress, high precision, increased cutting efficiency, and automatic knife change to achieve full automation.

2. Equipment configuration introduction

(I): The upper dust brush floating structure increases the service life of the milling knife.

£¨¶þ£©£ºAutomatic tool changing system, realize automation to save time, reduce human factors, high precision and strong stability.

£¨Èý£©£ºDouble spindle and double working platform structure design improves cutting and panel splitting efficiency.
